Works seamlessly with Linux, Android, Windows, and mac OS
Switch to ID mode to avoid nearby 2D code misreads
Smoothly scans coated barcodes and mobile payment QR codes
Fast and precise scanning of universal 1D and 2D codes
Wide scanning angle with an extended range for improved accuracy
Soft, eye-friendly lighting for comfortable use
| Performance Parameters | |
| Light Sources | Red LED |
| Supported Symbologies | 1D & 2D barcodes (as per device capability) |
| System compatibility | Linux, Android, Windows XP/7/8/10 |
| Scan Range | Code39 (5mil): 0–120mm, Code39 (20mil): 0–240mm, QR (20mil): 0–210mm |
| Print Contrast | 20% minimum reflective difference |
| Minimum recognition accuracy | Code39 4mil |
| Motion Tolerance | 4 meters/second |
| Scan Mode | Continuous Scanning |
| Image (Pixels) | 1024 (H) × 1280 (V) |
| Recognition angle range | Turn ±360°, Elevation ±65°, Declination ±65° |
| Man-machine Interaction | |
| Indicator light | Red & Blue dual color indicator (Blue: power/scan, Red: QR off) |
| Buzzer | Start prompt, read code prompt |
| Key | Switch three tones, 1D code switch |
| Interface | |
| Interface | USB (Drive-Free), RS232, USB-COM |
| Physical Parameters | |
| Dimensions | 152mm × 82mm × 152mm |
| Weight | 497.1g |
| Material | ABS + PC |
| Cable Length | 2M |
| Electronic Parameters | |
| Working Voltage | DC5V ±5% |
| Current | Start-up 380mA, Standby 190mA, Working 240mA |
| Environmental Parameters | |
| Operating Temperature | -20°C ~ 60°C |
| Storage Temperature | -30°C ~ 70°C |
| Relative Humidity | 5% ~ 95% RH (non-condensing/non-freezing) |
| Shock Resistance | Withstands multiple 1.5 meters drops to concrete |
| Ambient Light Immunity | 0 – 100,000 Lux |
