PRODUCT FEATURES
• Megapixel ultra-fast scanning
• Advanced Chip scans 1D, 2D, and damaged barcodes
• Easy plug-and-play setup for quick use
• Flexible Scan Window adapts to various scanning requirements.
• Buzzer and light for clear scanning feedback
• Ultra-low error rate of 1 in 5 million scans
SPECIFICATION
| Performance Parameters | |
| Sensor pixels | 1024(H) × 1280 pixels(V) |
| Scan Range | 0-240mm (EAN 13, 13mil, PCS=90%) |
| Print Contrast | 20% |
| Motion Tolerance | 4 meters/second |
| Scan Mode | Automatic Induction Scanning |
| Field of view | 44°(H), 34°(V) |
| Recognition angle range | Turn ±360°, Elevation ±65°, Declination ±65° |
Man-machine Interaction |
|
| Indicator light | Blue light flashing code reading prompt, blue light power indicator |
| Buzzer | Startup prompt, code reading prompt |
| Fill light | Red |
| Interface | |
| Interface | USB (Drive-Free), RS232, USB-COM |
| Physical Parameters | |
| Dimensions | 96mm × 108mm × 150mm |
| Weight | 294.4g |
| Material | ABS + PC |
| Cable Length | 2M |
Environmental Parameters |
|
| Storage Temperature | -30°C~70°C |
| Relative Humidity | 5%~95% RH (Non-condensing) |
| Ambient light intensity | 0~100000 LUX |
| Shock Resistance | Withstands multiple times 1.5 meters drops to concrete |
| Operating Temperature | -20°C~60°C |
Electronic Parameters |
|
| Working Voltage | DC5V±5% |
| Operating Current | Working current 240mA; Standby current 190mA |
