PRODUCT FEATURES
• 100m wireless range
• Advanced decoding chip for 1D & 2D barcodes
• Durable, shockproof and anti-fall ABS+PC material
• Bluetooth compatibility with various mobile devices
• USB receiver for quick, plug-and-play use
SPECIFICATION
Performance Parameters |
|
| Light Sources | White illumination light, green aiming light |
| Supported Symbologies | 1D: Codabar, Code39, Code32 Pharmaceutical (PARAF), Interleaved 2 of 5, NEC 2 of 5, Code93, Straight 2 of 5 Industrial, Straight 2 of 5 IATA, Matrix 2 of 5, Code 11, Code128, GS1-128, UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13, MSI, GS1 DataBar Omnidirectional, GS1 DataBar Limited, GS1 DataBar Expanded, Hong Kong 2 of 5, Korea Post 2D: Codeblock A, Codeblock F, PDF417, Micro PDF417, GS1 Composite Codes, QR Code, Data Matrix, MaxiCode, Aztec, HANXIN |
| Scanning Principle | Image CMOS |
| Resolution | 640 × 480 |
| Scan Mode | Manual / Continuous / Automatic Induction Scanning |
| Scan Angle | Yaw ±65°, Rotation 360°, Pitch ±65° |
| Depth of scan field | Code39 (5mil): 7-16 cm; Code39 (13mil): 7-32 cm; QR code (15mil): 3-18 cm; Code128 (20mil): 6-35 cm |
| Print Contrast | ≥20% |
| Error Rate | 1 / 5 million |
| Interface | USB-HID, USB-COM |
Wireless Communication |
|
| Pairing dedicated receiver | 2.4G communication |
| Pairing mobile Bluetooth devices | Dual-mode Bluetooth |
| Wireless transmission distance | 100 meters (open distance) |
Storage Mode |
|
| Offline storage mode | Scanner automatically stores data when it leaves connection range (200K characters capacity) |
| Inventory storage mode | Inventory mode storage capacity 200K characters |
| Pairing Mode | One-to-one: One scanner paired with one receiver; Scanner can pair with Bluetooth mobile device |
| Receiving end | Dedicated Bluetooth USB receiver, Android / iOS mobile device |
Environmental Parameters |
|
| Operating Temperature | -20°C ~ 50°C |
| Storage Temperature | -40°C ~ 70°C |
| Relative Humidity | 5% ~ 95% RH (Non-condensing) |
| Shock Resistance | Withstands multiple 1.5 meters drops to concrete |
Physical Parameters |
|
| Dimensions | 174.8 × 65.7 × 83.5 mm |
| Material | ABS + PC |
| Cable Length | 1 M |
Electronic Parameters |
|
| Working Voltage | DC5V ±5% |
| Battery Working | 7 hours |
| Charging Time | 3 hours |
| Lithium Battery | 2200 mAh |
| Standby Current | 0 mA (battery cut off in standby) |
| Working Current | No code scanning > 35 mA; Code scanning > 300 mA |
| Charging Model | Type-C charging cable, plug-in direct charging |
