PRODUCT FEATURES
• Advanced decoding chip for seamless interpretation of 1D and 2D barcodes
• Supports direct QR code transmission
• Easy plug-and-play setup with quick pairing
• Enhanced durability for longer wire life
SPECIFICATION
Performance Parameters |
|
| Light Sources | (Aimer) RED color LED, (Illumination) White color LED |
| Supported Symbologies | 1D: Codabar, Code 39, Code 32 Pharmaceutical (PARAF), Interleaved 2 of 5, NEC 2 of 5, Code 93, Straight 2 of 5 Industrial, Straight 2 of 5 IATA, Matrix 2 of 5, Code 11, Code 128, GS1-128, UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13, MSI, GS1 DataBar Omnidirectional, GS1 DataBar Limited, GS1 DataBar Expanded, Korea Post 2D: Codeblock A, Codeblock F, PDF417, Micro PDF417, GS1 Composite Codes, QR Code, Data Matrix, MaxiCode, Aztec, HANXIN |
| Image (Pixels) | 640 pixels (H) × 480 pixels (V) |
| Field of View | 39° (Horizontal), 29° (Vertical) |
| Print Contrast | 20% minimum reflective difference |
| Motion Tolerances | >1 m/s |
| Scan Angle | Yaw ±65°, Rotation 360°, Pitch ±65° |
| Depth of scan field | Code39 (5mil): 7-16 cm, Code39 (13mil): 7-32 cm, QR code (15mil): 3-18 cm, Code128 (20mil): 6-35 cm |
| Error Rate | 1 / 5 million |
| Interface | USB, USB-COM, RS232 |
Physical Parameters |
|
| Dimensions | 83.5 mm × 65.7 mm × 174.8 mm |
| Material | ABS + PC |
| Cable Length | 1.8 M |
| Environmental Parameters | |
| Operating Temperature | -20°C ~ 60°C |
| Storage Temperature | -30°C ~ 70°C |
| Relative Humidity | 5% ~ 95% RH (Non-condensing) |
| Ambient Lighting | 0 ~ 100000 LUX |
Electronic Parameters |
|
| Working Voltage | DC5V ±5% |
| Operating Current | 300 mA |
| Standby Current | 35 mA |
