SPECIFICATION
Printing |
|
| Printing Method | Thermal Transfer |
| Resolution | 203 dpi (BP4206e) / 300 dpi (BP4304e) |
| Max. Printing Speed | 6 ips (203 dpi) / 4 ips (300 dpi) |
| Max. Printing Width | 108 mm (203 dpi) / 106 mm (300 dpi) |
| Max. Printing Length | 1200 mm |
CPU |
|
| CPU | 32-bit RISC CPU |
Memory |
|
| RAM | 64 MB SDRAM |
| Flash | 128 MB Flash |
Detection |
|
| Sensor | Out-of-paper detection, gap detection, ribbon detection, black mark detection, cover-opening detection |
Media |
|
| Type | Black mark label, punched hole label, folding or rolling die cutting label |
| Width | 20 mm – 112 mm |
| Thickness | 60 μm – 200 μm |
| O.D. | Max. 5 inches (127 mm) |
| I.D. | 1 inch (25.4 mm), 1.5 inches (38 mm) |
Ribbon |
|
| Type | Wax, Wax/Resin, Resin |
| Width | 40 mm – 110 mm |
| Length | Max. 984 feet (300 m) |
| Core Diameter | 0.5 / 1 inch |
Programming Language |
|
| Language | ZPL, TSPL, EPL |
Software |
|
| Label Design Software | iDPRT BarTender Ultralite |
| Driver | Windows 7, 8, 10, Server 2012/2016/2018, Seagull Driver |
Resident Fonts |
|
| Bitmap Font | 6, 8, 12, 16, 32, OCR A & B, 90°, 180°, 270° rotatable |
| TTF Fonts | CG Triumvirate™ times expandable horizontally & vertically |
Codepage |
|
| Codepage | DOS437,720,737,755,775,850,852,855,856,857,858,860,862,863,864,865,866, Windows1250-1258, ISO8859-1-9,-15 |
Barcode |
|
| 1D | Code39, Code93, Code128UCC, Code128 A/B/C, Codabar, Interleave2of5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code11 |
| 2D | PDF417, Maxicode, DataMatrix, QR Code, Aztec |
Interface |
|
| Standard | USB, Ethernet |
| Optional | Bluetooth 5.0 / BLE, WiFi |
User Interface |
|
| Status Indicator | Two-color status light (standby / abnormal indication) |
| Buttons | Feed, Calibration button |
Power Supply |
|
| Input | AC 100-240 V, 50/60 Hz |
| Output | DC 24 V / 2 A |
Environment |
|
| Operation | 5°C – 40°C, humidity 30% – 85% |
| Storage | -20°C – 50°C, humidity 10% – 90% |
Physical Characteristic |
|
| Dimensions | 282 × 168 × 175 mm |
| Weight | 2.32 kg (excluding media) |
Options & Accessory |
|
| Accessories | Peeler module, cutter module, external label roll holder |
Agency Approval |
|
| Certification | CCC, CE, FCC, CB |
